Last Updated: March 6, 2008
Introduction
Here are some answers to frequently asked questions about Windows metafiles. If
your question isn't answered here, please send it to
Support@CompanionSoftware.com for possible inclusion in the next update
of this document.
NOTE: External sites are not necessarily endorsed by Companion
Software.
Table of Contents
Within this document, you will find information about:
What is a graphic?
For the purpose of our discussion, a graphic is any kind of image displayed
by a computer. This includes vector graphics and raster graphics.
What is a vector graphic?
A vector graphic is a graphic drawn as lines, polygons and text.
What is a raster graphic?
A raster graphic is a graphic drawn as an array of colored dots.
What is a metafile?
A metafile is a list of commands that can be played back to draw a graphic.
Typically, a metafile is made up of commands to draw objects such as lines, polygons
and text and commands to control the style of these objects. NOTE: Some people equate
metafiles with vector graphics. In most cases this is fine; but, strictly speaking,
a metafile can contain any mix of vector and raster graphics. For example, a metafile
could contain just one command to display a bitmap! Unless the distinction is important,
we will consider a metafile to be a kind of vector graphic in this FAQ.
What is a picture?
In the Windows world, picture is the generic, user-friendly name for a
metafile.
What is a bitmap?
A bitmap is a another name for a raster graphic. In Windows, these are
typically saved in a BMP file. However other common bitmap formats include GIF,
JPEG and PNG.
What are the tradeoffs between vector (metafile) and raster (bitmap) graphics?
In general, vector graphics take longer to display but can be scaled to any size
with no degradation. Raster graphics are faster to display but image quality suffers
when they are scaled up or down.
Also, there is a tradeoff between the size of a graphic and its complexity. The
vector graphic file needed to draw a cross-hatched rectangle full page on a 600-DPI
laser printer might be just a few hundred bytes; the comparable raster graphic might
be a thousand times bigger! On the other hand, the vector graphic file needed to
draw a detailed engineering drawing in a one inch square could be thousands of times
bigger than the corresponding raster graphic. So you can't say vector graphics are
smaller than raster graphics or vice versa. It depends on the graphic!
What is a Windows metafile (WMF file)?
A Windows metafile is a 16-bit metafile that can be used by 16- and 32-bit
versions of Microsoft Windows (3, 95, 98, Me, NT, 2000, XP and Vista) to display
a picture.
What is an enhanced metafile (EMF file)?
An enhanced metafile is a 32-bit metafile that can be used by 32-bit versions
of Windows (95, 98, Me, NT, 2000, XP and Vista) to display a picture. An enhanced
metafile can contain a much broader variety of commands than a "regular" Windows
metafile. Basically, the enhanced metafile format is a 32-bit super-set of the 16-bit
Windows metafile format.
How do Windows clipboard files (CLP files) relate to Windows metafiles?
A CLP file can simultaneously contain a graphic in Picture (WMF), Enhanced metafile
(EMF), Bitmap (BMP) and other formats. Some programs (such as
Metafile Companion) can extract these files from a CLP file.
Do Windows metafiles support the CMYK color space?
No. Windows metafiles are basically recordings of Windows graphics commands. Windows
GDI (Graphics Device Interface) solely uses an RGB color model, so any CMYK document/picture
(e.g. from Adobe Illustrator) when saved as an EMF (or WMF) file would lose any
CMYK information.
If you plan to import the picture into another application that does support CMYK,
consider using an intermediate format that does support CMYK (such as EPS, TIFF
or JPEG) that is supported by the importing application.
Can I convert a WMF file to an EMF file?
Yes. But there is no compelling reason to do this that I can think of. As of this
writing, most Windows programs both WMF and EMF files directly. However, if you're
really interested in doing the conversion, keep reading...
If you're a programmer, 32-bit versions of Windows can automatically convert between
WMF and EMF files. See the Win32 documentation on the SetWinMetaFileBits() and GetWinMetaFileBits()
functions for more details.
Mere mortals can use any number of image conversion programs to convert between
formats. For more details, see the
Graphics Conversion Software section of the Companion Software
Other Helpful Web Sites page.
Can I convert an EMF file to a WMF file?
Yes. The best reason to do this is you need to use the file in a program that doesn't
support EMF files. But beware! The WMF format is a subset of EMF format so you may
lose some information when doing the conversion.
If you're a programmer, 32-bit versions of Windows can automatically convert between
WMF and EMF files. See the Win32 documentation on the SetWinMetaFileBits() and GetWinMetaFileBits()
functions for more details.
Mere mortals can use any number of image conversion programs to convert between
formats. For more details, see the
Graphics Conversion Software section of the Companion Software
Other Helpful Web Sites page.
How can I convert a WMF (or EMF) file to PNG, GIF or JPEG format for use on
my Web page?
You can find links to a number of Windows conversion programs at the
Graphics Conversion Software section of the Companion Software
Other Helpful Web Sites page.
If you have a recent version of Office, you can open metafiles with the Microsoft
Office Picture Manager and then save them in the format you want with the File >
Export command. Another strategy is to create a Microsoft Word document containing
the WMF (or EMF) file(s) and then save it as HTML; this converts metafiles and other
graphics files in the document to GIF files. You can also use Metafile Companion
from Companion Software to copy the metafile to the clipboard, paste it to Windows
Paint and then save it in the desired format.
As a rule of thumb, use PNG or GIF for line art, clip art, etc. and use JPEG for
continuous-tone images (photographs).
How can I convert a BMP file to a WMF file?
Beware! There are two types of conversions that can be performed and they are very
different.
Most conversion programs convert a BMP to a WMF file by simply putting the bitmap
in a metafile "shell". The resulting WMF file is still essentially the same original
bitmap and gives you no particular advantange over the original BMP file. And this
kind of "bitmap disguised as a WMF file" cannot be edited by Metafile Companion.
For more details, see the
Graphics Conversion Software section of the Companion Software
Other Helpful Web Sites page.
However, some conversion programs "auto-trace" or "vectorize" the bitmap converting
areas of color to lines and polygons which are then stored in the WMF file. These
WMF files can be edited by Metafile Companion. If this is the
kind of conversion you want, check out the HiJaak
Pro product from IMSI or the
Adobe Illustrator product from Adobe
. Both claim to be able to trace bitmaps.
Another shareware program that can truly vectorize bitmap files is
KVEC from KK-Software.
KVEC offers a variety of conversion options, outputs many vector formats
(not just WMF) and is available on a variety of hardware platforms.
Can a Windows bitmap (BMP) file be transparent in some areas (like a GIF file)?
No. The Windows bitmap format does not support the idea of transparency. However,
the Windows metafile format does (see the next question).
Can I convert a Windows bitmap (BMP) file into a transparent
Windows metafile (WMF)?
In theory, yes. In practice, we are still looking for a good way to do this.
Basically, there are two approaches you can take:
- Put the bitmap in a metafile along with a transparency mask bitmap and use the proper
bitmap operations to apply the mask to the bitmap before displaying it on the screen,
or
- Convert the bitmap to a metafile by
"vectorizing" it (as described above) and then delete all objects of the background
color.
I don't know of any program that can do approach number 1. You can do approach number
2 by using one of the
vectorizing programs described above to convert from bitmap to metafile
format. Then use a program like
Metafile Companion to select and delete all the background color
objects.
Does a WMF or EMF printer driver exist?
The HiJaak Pro product from
IMSI adds a "Print Capture" printer driver that can capture output from
any Windows program into any of its supported graphics formats including WMF or
EMF.
Should I get clip art in vector (metafile) or raster (bitmap) format?
The rule of thumb is, get clip art in the form it was created. For most clip art,
this means getting it in a vector format (Windows metafile, EPS file, etc.). In
vector format, clip art can be scaled to any size you want without loss of quality.
However, if the original graphic was a photograph (continuous-tone image) that was
scanned in as a raster graphic (bitmap, BMP, GIF, JPEG, PNG, etc.), then get the
bitmap format.
Where can I find vector format (WMF/EMF) clip art?
A variety of vendors offer clip art in WMF format. A good place to start looking
is at the
Clip Art section of the Companion Software
Other Helpful Web Sites page. You might also want to visit the Companion
Software
Links to Free Clip Art.
How can I edit my vector format (WMF/EMF) clip art?
Most modern Windows drawing programs (such as Microsoft PowerPoint, Adobe Illustrator,
etc.) can import and edit Windows metafiles. However, most have their limitations
and
idiosyncracies. The one program that was designed just to edit WMF files
is
Metafile Companion.
Why does my metafile "change" in some programs
when I import it?
Often, drawing programs import a metafile by reading it and converting each metafile
object to the closest corresponding drawing object. No drawing program that I am
aware of supports all the possible objects contained in a Windows metafile.
And some don't always draw objects the same way Windows does.
Most often drawing programs don't handle things like PolyPolygons (polygons with
holes and islands), rotated text, bitmap fill patterns and transparent hatch patterns.
This can cause certain "idiosyncracies" to appear when editing some metafiles.
If you want to put your favorite drawing program to the test, use it to open
TEST.WMF, and make a small change to one of the objects (to make sure the
metafile has really been converted to the drawing program's native format). Then
use the Windows Clipboard Viewer to open
TEST.CLP and see what the chart should really look like! Are they
the same? (They are if you're using
Metafile Companion!)
Why do some programs display a metafile properly when it is imported, but then
change it when I edit it?
This is related to the
previous question. Basically, any Windows program can accurately display
a Windows metafile with a few lines of code. They just hand the metafile to Windows
and say "display it". So some drawing programs take the following approach with
metafiles. Initially, when the metafile is added they display it "as is". But as
soon as the user tries to edit (or ungroup) the metafile, then they convert it to
their own internal format and that's where the
idiosyncracies occur.
Are there any drawing programs that can edit a metafile without changing it?
Metafile Companion from Companion Software is a pretty good metafile
editor. But even it doesn't support every metafile command.
Can I use WMF or EMF graphics in my web pages?
Browsers don't support viewing WMF or EMF files directly like they do GIF, JPEG
and PNG. However, there is a browser plug-in available for the Netscape and Microsoft
browsers that can display EMF files on a web page. See
http://www.emfviewer.com/ for details.
You may also want to check out the Scalable
Vector Graphics (SVG) standard. This is the true "metafile for the Web"
that has limited but growing browser support.
Where can I find information about the internal structure of Windows metafiles
(WMF files) and enhanced metafiles (EMF files)?
The first place to check is the Microsoft Developer
Network site since Microsoft created these file formats.
Another great resource is the now out-of-print Encyclopedia
of Graphics File Formats from O'Reilly.
You might also want to check out
Windows Metafiles - a guide for non-windows programmers.
Where can I find information about the internal structure of Windows clipboard
files (CLP files)?
On the Microsoft Developer Network. (Déja
vû all over again.)
The Encyclopedia of Graphics File Formats (mentioned above) also has information
about the CLP file format.
How can I list the records inside a particular metafile?
On the Microsoft Developer Network site,
there are a couple of sample Windows programs called WMFDCODE and
EMFDCODE that can display a metafile and list its contents.
Other utilities to list the contents of metafiles can be found at the
Metafile Listing Utilities section of the Companion Software
Windows Metafile Resource Center.
How can I compare two metafiles to see if they are equivalent?
You could compare two metafiles using the DOS COMP or FC command. However, this
doesn't always work. Sometimes, metafiles produce identical output but have random
"garbage" bytes in unused portions of the file. Other times they contain a "comment"
record that includes the filename or other information that doesn't affect the actual
output. So, for example, if you open one WMF file (with a program like
Metafile Companion), save it with a new name and then do a "binary"
compare of the files, the two files won't compare.
The answer to these problems is to do a "conceptual compare" of the actual metafile
records themselves excluding any comments. A simple way to to this is to do a binary
compare of the listings of two metafiles.
Utilities to compare the listings of metafiles can be found at the
Metafile Compare Utilities section of the Companion Software
Windows Metafile Resource Center.
Is it true that just viewing a WMF file could allow someone to take over my
machine?
The short answer is "yes, on older versions of Windows". For all the details, see
Microsoft
Security Bulletin MS06-001: Vulnerability in Graphics Rendering Engine Could Allow
Remote Code Execution. However, this is no longer a problem for Windows
XP Service Pack 2 or later. Also, few if any exploitations of this vulnerability
have been reported.
